P5 Large Outdoor SMD LED Display Clear High Definition RoHS Certificated

    Buy cheap P5 Large Outdoor SMD LED Display Clear High Definition RoHS Certificated from wholesalers

    Buy cheap P5 Large Outdoor SMD LED Display Clear High Definition RoHS Certificated from wholesalers
    • Buy cheap P5 Large Outdoor SMD LED Display Clear High Definition RoHS Certificated from wholesalers

    P5 Large Outdoor SMD LED Display Clear High Definition RoHS Certificated

    Ask Lasest Price
    Brand Name : TOPLED
    Model Number : P5
    Certification : CE FCC ROHS
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 5000 Square Meter/Square Meters per Month
    Delivery Time : 10-15 working days after got deposit
    • Product Details
    • Company Profile

    P5 Large Outdoor SMD LED Display Clear High Definition RoHS Certificated


    Clear High Definition P5 Large LED Display Full Color 6500 Nits Brightness

    Specification:


    Pixel Pitch5mm
    Pixel Density40000dots/sq.m
    Color Configuration1R1G1B
    LED PackageSMD2727
    DisplayFull Color
    Module Size160mm x 160mm
    Module Resolution32dots x 32dots
    Drive Duty1/8 Scan
    Standard Cabinet Size960*960mm
    Cabinet Weight45kg
    Led ChipNationstar / Kinglight
    PowerDC 5V, AC110V-220V
    Brightness≥6500 cd/sqm
    Viewing Distance5M
    Viewing AngleH: 140°; V:140°
    Refresh Rate>1920HZ, adjustable by software
    Power InputAC110V/ 220V ±10%, 50HZ
    Max Power Consumption900W/cabinet
    Ave. Power Consumption300W/cabinet
    Temperature-40℃~+65℃
    MTBF>10,000 Hours
    Life Span>100,000 Hours
    Waterproof LevelIP65
    Operating Humidity10%~90% RH
    Control MethodSynchronous, Asynchronous,
    CertificateCE, RoHS,ISO9001

    Product Description:

    1) High refresh rate , high brightness and high contrast

    2) The brightness can be adjustable to meet the need of changing environment.

    3) Wide viewing angle: The horizontal and vertical viewing angles are so wide that it is suitable for wide horizontal.

    4) Environment protection, antistatic, dust-proof, waterproof ,good heat dissipation, cost-effective .

    5) Error detection and monitoring:it can monitor the inner temperature,voltage,cooling fans etc and
    error detection automatically.

    6) High reliability: using distributed scanning technology and module design technology that make
    higher reliability and stability.

    7) Steady and reliable system:with strong anti-interference ability and long service life that can
    continually work for over 24 hours, and it’s easy to operate the system.

    8) Convenient installation and maintenance of display modules.



    Application:



    Quality P5 Large Outdoor SMD LED Display Clear High Definition RoHS Certificated for sale
